Router on a Stick (ROAS): A Practical Guide to Inter-VLAN Routing

by · Published · Updated

In modern networks, Virtual Local Area Networks (VLANs) are commonly used to segment traffic for better organization, security, and efficiency. However, devices in different VLANs cannot communicate with each other without a routing device. One of the low cost, effective and straightforward technique that can enable inter-VLAN communication is known as Router on a Stick (ROAS).

What is Router on a Stick (ROAS)?

Router on a Stick is a network configuration that enables inter-VLAN routing using a single physical interface on a router. It allows multiple VLANs on a switch to communicate through one trunk link between the switch and the router. This setup is commonly used in small to medium-sized networks due to its simplicity and cost-effectiveness.

Router on a Stick is a network configuration that enables inter-VLAN routing using a single physical interface on a router

How Router on a Stick (ROAS) Works?

  1. Single Physical Link
    • One Ethernet cable connects the router and the switch.
    • This link is configured as a trunk port to carry traffic from multiple VLANs.
  2. VLAN Tagging (802.1Q)
    • The switch tags each frame with a VLAN ID using the 802.1Q protocol.
    • The router reads these tags to direct traffic appropriately.
  3. Router Sub-interfaces
    • The physical router interface is divided into virtual sub-interfaces.
    • Each sub-interface:
      • Is assigned to a specific VLAN.
      • Has its own IP address (acts as the default gateway for that VLAN).
      • Handles traffic for that VLAN using VLAN tagging.
  4. Inter-VLAN Routing
    • The router routes traffic between VLANs internally using its routing table.
    • Devices in different VLANs communicate via the router’s sub-interfaces.

Benefits of Router on a Stick (ROAS)

  1. Cost-Effective
    • Eliminates the need for expensive Layer 3 switches.
    • Ideal for budget-conscious or smaller network deployments.
  2. Simplified Setup
    • Easier to configure in environments with limited routing infrastructure.
    • Uses familiar commands and interface settings for most network admins.
  3. Scalable for Moderate Networks
    • Handles inter-VLAN routing for networks with moderate traffic.
    • Suitable for labs, branch offices, and SMBs.

Limitation of Router on a Stick (ROAS)

  1. Limited Bandwidth
    • All inter-VLAN traffic shares one physical link, potentially causing a bottleneck in high-traffic environments.
    • Single Point of Failure
    • If the router or trunk link fails, all VLAN communication stops.
  2. Requires Technical Understanding
    • While simple in design, it demands a working knowledge of:
      • VLANs
      • Sub-interface configuration
      • Trunking and routing principles
  3. Not Suitable for Large Networks
    • High-performance or enterprise networks should use Layer 3 switches instead for better speed, redundancy, and scalability.

When to Use and Not Use Router on a Stick (ROAS)?

Best suited for:

  • Small to medium businesses (SMBs)
  • Training labs or test environments
  • Branch offices with limited network hardware

Avoid in:

  • High-availability or mission-critical networks
  • Networks with heavy inter-VLAN traffic
  • Environments requiring advanced routing features

Conclusion

Router on a Stick (ROAS) is a practical, low-cost method for inter-VLAN communication using a single router interface and a trunk link. While it’s not suitable for high-traffic or enterprise environments, it’s an effective solution for smaller networks that need simple and reliable VLAN routing.
